Product Introduction
The independently developed second-generation off-grid energy storage and power generation system module can be connected in parallel to form larger capacity power generation systems based on power requirements. It is widely applicable in various fields such as continuous power and heat supply for field operations at high and low altitudes, microgrid hydrogen energy storage, and vehicle off-grid fast charging.
Technical Specifications
- Rated Output Power 0 – 200 KW (Continuous & Stable)
- Peak Power 200 KW
- Power Generation Efficiency (@≤100KW, 3000m altitude) > 50%
- Hydrogen Consumption (@100KW) 7 Nm³/h
- Output Voltage 380 VAC (Customizable)
- Operating Temperature -25 ℃ to +45 ℃
- Combined Heat & Power Efficiency > 90%
- Dimensions (L×W×H) 3600 × 1350 × 2300 mm
- Weight 9 Tons
- Noise Level < 65 dB
- DC Power for Vehicle Fast Charging ≥ 40 KW
- Protection Rating IP54
- Potable Water Output Standard Complies with GB 5749-2022
- Black Start Capability Yes
- Oxygen-Rich Environment Operation Supported
- Combined Heat & Power (CHP) Yes
- Carbon Emissions 0
